Cov khoom siv qib 5 Titanium
Qib 5 titanium (Ti-6Al-4V) yog siv nyob rau hauv ntau yam khoom ntawm cov neeg siv khoom vim nws cov khoom siv zoo heev, cov yam ntxwv sib sib zog nqus thiab zoo biocompatibility.
Hauj lwm lawm
Qhov zoo ntawm Qib 5 titanium ntawv:
Corrosion kuj: ncua cov khoom lub neej thiab txo tus nqi kho.
Biocompatibility: Tsis muaj kev phom sij rau tib neeg lub cev, haum rau cov khoom uas hnav rau lub sijhawm ntev lossis sib cuag nrog daim tawv nqaij.
Aesthetics: Cov xim hlau tshwj xeeb zoo nkauj thiab xim ntxiv rau kev zam thiab kev nyiam ntawm cov khoom.
Lub teeb yuag: txo qhov hnyav ntawm cov khoom thiab txhim kho kev nplij siab ntawm kev siv.
Cov txheej txheem tsim khoom thawj zaug rau Qib 5 muaj titanium nplooj ntawv
| Thermal Properties | ||||
|
||||
| CTE, linear 20 degree | 8.6 µm / m- degree | 4.78 µin/in-degree F | 20-100ºC | |
| CTE, linear 250 degree | 9.2 µm / m- degree | 5.11 µin/in-degree F | Qhov nruab nrab tshaj qhov ntau ntawm 20-315ºC | |
| CTE, linear 500 degree | 9.7 µm / m- degree | 5.39 µin/in-degree F | Qhov nruab nrab tshaj qhov ntau ntawm 20-650ºC | |
| Tshwj xeeb kub muaj peev xwm | 0.5263 J/g- degree | 0.126 BTU/lb- degree F | ||
| Thermal conductivity | 6.7 W/m-K | 46.5 BTU-in/hr-ft²-degree F | ||
| Melting Point | 1604 - 1660 degree | 2920 - 3020 degree F | ||
| Solidus | 1604 degree | 2920 degree F | ||
| Liquidus | 1660 degree | 3020 degree F | ||
| Beta Transus | 980 degree | 1800 degree F | ||
Daim ntawv thov rau Qib 5 titanium alloys:
Ncej: Qib 5 titanium feem ntau yog siv los tsim cov thav ntawv rau cov tsom iav qib siab. Nws tsis yog tsuas yog hnav, tab sis kuj muaj lub zog siab thiab corrosion kuj, ua rau nws yooj yim dua thiab ruaj khov.
Cov koom haum ntaus golf: Qib 5 titanium yog siv dav hauv kev tsim cov taub hau golf, tshwj xeeb tshaj yog cov tsav tsheb. Nws lub siab modulus ntawm elasticity thiab tsawg ntom pab kom pob ceev thiab nyob deb.
Watch Cases thiab Straps: Ntau lub khw muag khoom high-end siv Qib 5 titanium rau cov ntaub ntawv saib thiab cov hlua vim nws yog ob qho tib si hnyav thiab ruaj khov. Cov khoom siv no kuj muaj qhov zoo corrosion thiab khawb tsis kam los tswj cov tsos thiab kev ua haujlwm ntawm lub moos.
Loj-scale Hoobkas ntau lawm ntawm Qib 5 alloy titanium ntawv
Pab neeg tshaj lij thiab lees paub muab qib 5 nyias titanium ntawv
Lub tuam txhab tau txais iso9001: 2015 kev tswj hwm kev tswj hwm kev lees paub, iso14001: 2015 ib puag ncig kev tswj hwm daim ntawv pov thawj, ISO 45001: 2018 kev ua haujlwm kev noj qab haus huv thiab kev tswj hwm kev nyab xeeb ntawv pov thawj, PED 2014/68 / EU Cov Khoom Siv Hluav Taws Xob Cov Lus Qhia GL cov ntaub ntawv pov thawj, ntawv pov thawj, SGS daim ntawv pov thawj khoom zoo thiab lwm yam ntawv pov thawj thiab kev tsim nyog. Peb nruj me ntsis siv GB / T 3639-2009, ASTM A519, DIN2391, JIS G3445 thiab lwm cov qauv hauv tebchaws thiab thoob ntiaj teb kom ntseeg tau tias peb cov khoom zoo.
